© Precor Incorporated, Unauthorized Reproduction and Distribution Prohibited by Law
Figure 331: Gas Shock
Caution: It is recommended to have assistance available for following
step(s).
20 With the assistance, lift the front of the Incline platform until
the Incline tube mounting holes align with the Incline platform
mounting holes.
21 Replace the Incline motor mounting pin through the Incline tube and
Incline platform and attach the hitch pin.
22 Replace the wave washer and flat belt pulley, secure the flat belt
pulley with the snap ring.
23 Lift the stairarms and thread the inside flat belts through the flat
belt pulleys.
24 Replace the covers per procedure, Cover Replacement (on page 152).
25 Operate the incline through its entire range to ensure proper
operation.
