© Precor Incorporated, Unauthorized Reproduction and Distribution Prohibited by Law
Inspecting and Adjusting the H-brake Belt Tension
WARNING: Before continuing with this procedure, review the Warning and
Caution statements listed in the Warning and Caution Statements and
General Safety Guidelines Section, Things You Should Know.
Procedure
1 Remove the gasket, top, front, rear, left and right side covers
per, Cover Replacement (on page 152) Procedure .
2 Place a belt gauge on the H-brake belt.
Figure 50: H-Brake Belt Tension Gauge
