c) All cables are good and connected but there is no signal at the
drop
2 TV channel is not being received or is not a valid channel
3 USB cable connecting tuner to screen is loose or plugged in
incorrectly
4 Media player has failed (software)
5 Watchdog may or may not be recovering the media player automatically
6 There may be a software mismatch between the CPA and the MFE.
7 Tuner has failed (hardware).
Figure 46: Coax Cable & TV Tuner USB Cable
Possible Remedies
8 Check for video signal to the tuner
9 Inspect jumper cables connecting fitness equipment to the video
drop. If it is visibly damaged or disconnected, replace or
reconnect. If it passes visual inspection, swap with a known good.
If TV channel now appears, the cable is the cause. Replace the
jumper cable. If the channel does not appear, perform the same
check on the F connectors.
10 Inspect the cable that runs from the patch panel at the bottom of
the machine to the console. If this is disconnected or damaged,
reconnect or replace. If the cable passes visual inspection, use a
known good cable to bypass this cable. If the TV channel appears,
replace the coax cable running through the machine.
