11 With the assistance, lift the front of the Incline platform until
the Incline tube mounting holes align with the Incline platform
mounting holes.
12 Replace the Incline motor mounting pin through the Incline tube and
Incline platform and attach the hitch pin.
13 Lift the stairarms and thread the inside flat belts through the flat
belt pulleys.
14 Replace the covers per procedure, Cover Replacement (on page 152).
15 Operate the incline through its entire range to ensure proper
operation.
Replacing the Incline Motor
Procedure
1 Remove the covers per procedure, Cover Replacement (on page 152).
2 Remove the lower PCA cover as per procedure, Replacing the Lower PCA
and Battery Bracket (on page 270).
3 Disconnect the incline motor cable connector from the lower PCA and
detach the cable from the lower PCA battery bracket cable retainer.
Gas Shock Removal
4 Release tension from the top of the gas shock by pushing a # 1 flat
top screw driver in the slot under the tension clip. Do not
completely remove the retaining clip as it is difficult to
reinstall.
Tip: If the incline motor is jammed at full elevation, remove the lower retaining
clip to facilitate the gas shock removal.
5 Using another flat head screw driver as a pry bar, place the screw
driver head between the frame and the top of the gas shock and pry
the shock off the upper mounting stud.
6 Rotate the gas shock down and out of the way of the incline motor.
