© Precor Incorporated, Unauthorized Reproduction and Distribution Prohibited by Law
3 The belt gauge should read approximately 110 lbs. If the belt
tension is significantly high or low the belt tension may be
adjusted by loosening or tightening the H-Brake adjustment bolt.
Figure 51: H-Brake Belt and H-Brake Cam
Inspecting and Adjusting the Generator Belt Tension
WARNING: Before continuing with this procedure, review the Warning and
Caution statements listed in the Warning and Caution Statements and
General Safety Guidelines Section, Things You Should Know.
