Figure 36: P80 Rear Cover Removal
2 Remove the four flat head 5/8 inch long screws that secure the
console to the plate.
Figure 37: Console Mounting Screws
3 Tilt the console forward (away from yourself) on the mounting hook.
Equation 1: Console Mounting Hook
