Precor AMT Series User Manual

© Precor Incorporated, Unauthorized Reproduction and Distribution Prohibited by Law
Page 213
Figure 138: Flat Belt Terminal Covers
Flat Belt Removal - Rear Terminal
Note: Any time the flat belt terminal screws are removed from the flat belt
clamp or cams, the screws must be discarded and replaced with new
screws.
10 Remove and discard the two 1/4-20X1 screws and shims that secure the
flat belt to the clamp.
Figure 139: Flat Belt Removal - Terminal

Precor AMT Series Specifications

General

Brand	Precor
Model	AMT Series
Category	Elliptical Trainer
Language	English
