RL78/F13, F14 CHAPTER 15 SERIAL ARRAY UNIT

R01UH0368EJ0210 Rev.2.10 998

Dec 10, 2015

(3) Processing flow

Figure 15-145. Timing Chart of Address Field Transmission

Remark m: Unit number (m = 0, 1), n: Channel number (n = 0, 1), r: IIC number (r = 00, 01, 10, 11),

mn = 00, 01, 10, 11

D7 D6 D5 D4 D3 D2 D1 D0

R/W

D7 D6

SSmn

SEmn

SOEmn

SDRmn

SCLr output

SDAr output

SDAr input

Shift

INTIICr

TSFmn

D5 D4 D3 D2 D1 D0

ACK

Address

Shift operation

Address field transmission

SOmn bit manipulation

CKOmn

bit manipulation
