Renesas RL78 Series User Manual

RL78/F13, F14 CHAPTER 17 LIN/UART MODULE (RLIN3)
R01UH0368EJ0210 Rev.2.10 1226
Dec 10, 2015
(b) UART Buffer Transmission
The LIN/UART module (in UART mode) has a maximum of nine bytes of UART buffers, and thus it is capable of
performing continuous transmissions through the use of UART buffers.
Figure 17-25 shows the UART buffer transmission operation in the LIN/UART module (in UART mode). Table
17-19 shows the UART buffer transmission processing.
Figure 17-25. UART Buffer Transmission in LIN/UART Module (in UART mode)
ST: Start bit
P: Parity bit
SP: Stop bit
IBS: Inter-byte space
Data 0 Data 1 Data (N-1) Data N
PPP PP
S
T
S
T
S
T
S
T
S
T
S
P
S
P
S
P
S
P
S
P
IBS IBS
IBS IBS
(1) (3)(4) (5) (6) (7) (8)(9) (10)(11)
(12)(13)(2)

Renesas RL78 Series Specifications

General

Core	RL78
CPU Clock Speed	Up to 32 MHz
Flash Memory	Up to 512 KB
RAM	Up to 32 KB
Operating Voltage	1.6 V to 5.5 V
Low Power Modes	HALT, STOP, SNOOZE
CPU Architecture	16-bit
Temperature Range	-40°C to +85°C
Package	LQFP
Timers	16-bit timers
Communication Interfaces	UART, I2C, LIN
A/D Converter	12-bit
