RL78/F13, F14 CHAPTER 18 CAN INTERFACE (RS-CAN LITE)
R01UH0368EJ0210 Rev.2.10 1266
Dec 10, 2015
Table 18-3. List of CAN Module Registers (4/22)
Address Special Function Register (SFR) Name Symbol R/W Access Size After
Reset
1 bit 8 bits 16 bits
F03B0H CAN receive rule entry register 1BL
Note 1
GAFLML1L GAFLML1 R/W — √ √ 0000H
F03B1H GAFLML1H — √
F03B0H CAN receive buffer register 1AL
Note 2
RMIDL1L RMIDL1 R — √ √ 0000H
F03B1H RMIDL1H — √
F03B2H CAN receive rule entry register 1BH
Note 1
GAFLMH1L GAFLMH1 R/W — √ √ 0000H
F03B3H GAFLMH1H — √
F03B2H CAN receive buffer register 1AH
Note 2
RMIDH1L RMIDH1 R — √ √ 0000H
F03B3H RMIDH1H — √
F03B4H CAN receive rule entry register 1CL
Note 1
GAFLPL1L GAFLPL1 R/W — √ √ 0000H
F03B5H GAFLPL1H — √
F03B4H CAN receive buffer register 1BL
Note 2
RMTS1L RMTS1 R — √ √ 0000H
F03B5H RMTS1H — √
F03B6H CAN receive rule entry register 1CH
Note 1
GAFLPH1L GAFLPH1 R/W — √ √ 0000H
F03B7H GAFLPH1H — √
F03B6H CAN receive buffer register 1BH
Note 2
RMPTR1L RMPTR1 R — √ √ 0000H
F03B7H RMPTR1H — √
F03B8H CAN receive rule entry register 2AL
Note 1
GAFLIDL2L GAFLIDL2 R/W — √ √ 0000H
F03B9H GAFLIDL2H — √
F03B8H CAN receive buffer register 1CL
Note 2
RMDF01L RMDF01 R — √ √ 0000H
F03B9H RMDF01H — √
F03BAH CAN receive rule entry register 2AH
Note 1
GAFLIDH2L GAFLIDH2 R/W — √ √ 0000H
F03BBH GAFLIDH2H — √
F03BAH CAN receive buffer register 1CH
Note 2
RMDF11L RMDF11 R — √ √ 0000H
F03BBH RMDF11H — √
F03BCH CAN receive rule entry register 2BL
Note 1
GAFLML2L GAFLML2 R/W — √ √ 0000H
F03BDH GAFLML2H — √
F03BCH CAN receive buffer register 1DL
Note 2
RMDF21L RMDF21 R — √ √ 0000H
F03BDH RMDF21H — √
F03BEH CAN receive rule entry register 2BH
Note 1
GAFLMH2L GAFLMH2 R/W — √ √ 0000H
F03BFH GAFLMH2H — √
F03BEH CAN receive buffer register 1DH
Note 2
RMDF31L RMDF31 R — √ √ 0000H
F03BFH RMDF31H — √
F03C0H CAN receive rule entry register 2CL
Note 1
GAFLPL2L GAFLPL2 R/W — √ √ 0000H
F03C1H GAFLPL2H — √
F03C0H CAN receive buffer register 2AL
Note 2
RMIDL2L RMIDL2 R — √ √ 0000H
F03C1H RMIDL2H — √
F03C2H CAN receive rule entry register 2CH
Note 1
GAFLPH2L GAFLPH2 R/W — √ √ 0000H
F03C3H GAFLPH2H — √
F03C2H CAN receive buffer register 2AH
Note 2
RMIDH2L RMIDH2 R — √ √ 0000H
F03C3H RMIDH2H — √
F03C4H CAN receive rule entry register 3AL
Note 1
GAFLIDL3L GAFLIDL3 R/W — √ √ 0000H
F03C5H GAFLIDL3H — √
Notes 1. These registers are allocated to RAM window 0 for the CAN module (receive rules and CAN RAM test
register). When setting these registers, set the RPAGE bit in the GRWCR register to 0.
2. These registers are allocated to RAM window 1 for the CAN module (receive buffer, receive FIFO buffer,
transmit/receive FIFO buffer, transmit buffer, and transmit history data). When setting these registers, set the
RPAGE bit in the GRWCR register to 1.
To Next Page
