Renesas RL78 Series User Manual

RL78/F13, F14 CHAPTER 36 ELECTRICAL SPECIFICATIONS (GRADE Y)
R01UH0368EJ0210 Rev.2.10 1826
Dec 10, 2015
(4) When AVREF (+) = internal reference voltage (ADREFP1 = 1, ADREFP0 = 0), AVREF (-) = AVREFM/ANI1
(ADREFM = 1), target ANI pin: ANI0 to ANI23, ANI24 to ANI30
(TA = -40 to +150C, 2.7 V  EVDD0 = EVDD1 = VDD  5.5 V, VSS = EVSS0 = EVSS1 = 0 V, Reference voltage (+) = VBGR,
Reference voltage (-) = AV
REFM = 0 V)
Parameter Symbol Conditions MIN. TYP. MAX. Unit
Resolution RES 8 bit
Conversion time tCONV 8-bit resolution 2.7 V  VDD  5.5 V 17 39
µs

Zero-scale error
Notes 1, 2
EZS 8-bit resolution 2.7 V  VDD  5.5 V 0.60 %FSR
Integral linearity error
Note 1
ILE 8-bit resolution 2.7 V  VDD  5.5 V 2.0 LSB
Differential linearity error
Note 1
DLE 8-bit resolution 2.7 V  VDD  5.5 V 1.0 LSB
Reference voltage (+) VBGR 1.38 1.45 1.52 V
Analog input voltage VAIN 0 VBGR V
Notes 1. Excludes quantization error (1/2 LSB).
2. This value is indicated as a ratio (%FSR) to the full-scale value.

Renesas RL78 Series Specifications

General

Core	RL78
CPU Clock Speed	Up to 32 MHz
Flash Memory	Up to 512 KB
RAM	Up to 32 KB
Operating Voltage	1.6 V to 5.5 V
Low Power Modes	HALT, STOP, SNOOZE
CPU Architecture	16-bit
Temperature Range	-40°C to +85°C
Package	LQFP
Timers	16-bit timers
Communication Interfaces	UART, I2C, LIN
A/D Converter	12-bit
