RL78/F13, F14 CHAPTER 3 CPU ARCHITECTURE
R01UH0368EJ0210 Rev.2.10 157
Dec 10, 2015
Table 3-6. Extended SFR (2nd SFR) List (6/32)
Address Special Function Register (2nd SFR) Name Symbol R/W Manipulable Bit Range After reset
1-bit 8-bit 16-bit
F01C6H Timer counter register 13 TCR13 R – –  FFFFH
F01C7H
F01C8H Timer counter register 14 TCR14 R – –  FFFFH
F01C9H
F01CAH Timer counter register 15 TCR15 R – –  FFFFH
F01CBH
F01CCH Timer counter register 16 TCR16 R – –  FFFFH
F01CDH
F01CEH Timer counter register 17 TCR17 R – –  FFFFH
F01CFH
F01D0H Timer mode register 10 TMR10 R/W – –  0000H
F01D1H
F01D2H Timer mode register 11 TMR11 R/W – –  0000H
F01D3H
F01D4H Timer mode register 12 TMR12 R/W – –  0000H
F01D5H
F01D6H Timer mode register 13 TMR13 R/W – –  0000H
F01D7H
F01D8H Timer mode register 14 TMR14 R/W – –  0000H
F01D9H
F01DAH Timer mode register 15 TMR15 R/W – –  0000H
F01DBH
F01DCH Timer mode register 16 TMR16 R/W – –  0000H
F01DDH
F01DEH Timer mode register 17 TMR17 R/W – –  0000H
F01DFH
F01E0H Timer status register 10 TSR10L TSR10 R –   0000H
F01E1H – – –
F01E2H Timer status register 11 TSR11L TSR11 R –   0000H
F01E3H – – –
F01E4H Timer status register 12 TSR12L TSR12 R –   0000H
F01E5H – – –
F01E6H Timer status register 13 TSR13L TSR13 R –   0000H
F01E7H – – –
F01E8H Timer status register 14 TSR14L TSR14 R –   0000H
F01E9H – – –
F01EAH Timer status register 15 TSR15L TSR15 R –   0000H
F01EBH – – –
F01ECH Timer status register 16 TSR16L TSR16 R –   0000H
F01EDH – – –
F01EEH Timer status register 17 TSR17L TSR17 R –   0000H
F01EFH – – –
