Table 3-6. Extended SFR (2nd SFR) List (31/32)
Address Special Function Register (2nd SFR) Name Symbol R/W Manipulable Bit Range After
reset
1-bit 8-bit 16-bit
F0680H CAN0 transmit history buffer access register
Note
THLACC0L THLACC0 R – √ √ 0000H
F0681H THLACC0H – √
F06C1H LIN wakeup baud rate select register LWBR0/LWBR1 R/W – √ – 00H
F06C2H LIN/UART baud rate prescaler 0 register LBRP00/LBRP10 LBRP0/
LBRP1
R/W – √ √ 00H
F06C3H LIN/UART baud rate prescaler 1 register LBRP01/LBRP11 R/W – √ 00H
F06C4H LIN self–test control register LSTC0/LSTC1 R/W – √ – 00H
F06C5H UART standby control register LUSC0/LUSC1 R/W – √ – 00H
F06C8H LIN/UART mode register LMD0/LMD1 R/W – √ – 00H
F06C9H LIN/UART break field configuration register/
UART configuration register
LBFC0/LBFC1 R/W – √ – 00H
F06CAH LIN/UART space configuration register LSC0/LSC1 R/W – √ – 00H
F06CBH LIN wakeup configuration register LWUP0/LWUP1 R/W – √ – 00H
F06CCH LIN interrupt enable register LIE0/LIE1 R/W – √ – 00H
F06CDH LIN/UART error detection enable register LEDE0/LEDE1 R/W – √ – 00H
F06CEH LIN/UART control register LCUC0/LCUC1 R/W – √ – 00H
F06D0H LIN/UART transmit control register LTRC0/LTRC1 R/W – √ – 00H
F06D1H LIN/UART mode status register LMST0/LMST1 R – √ – 00H
F06D2H LIN/UART status register LST0/LST1 R/W – √ – 00H
F06D3H LIN/UART error status register LEST0/LEST1 R/W – √ – 00H
F06D4H LIN/UART data field configuration register LDFC0/LDFC1 R/W – √ – 00H
F06D5H LIN/UART ID buffer register LIDB0/LIDB1 R/W – √ – 00H
F06D6H LIN checksum buffer register LCBR0/LCBR1 R/W – √ – 00H
F06D7H UART data buffer 0 register LUDB00/LUDB10 R/W – √ – 00H
F06D8H LIN/UART data buffer 1 register LDB01/LDB11 R/W – √ – 00H
F06D9H LIN/UART data buffer 2 register LDB02/LDB12 R/W – √ – 00H
F06DAH LIN/UART data buffer 3 register LDB03/LDB13 R/W – √ – 00H
F06DBH LIN/UART data buffer 4 register LDB04/LDB14 R/W – √ – 00H
F06DCH LIN/UART data buffer 5 register LDB05/LDB15 R/W – √ – 00H
F06DDH LIN/UART data buffer 6 register LDB06/LDB16 R/W – √ – 00H
F06DEH LIN/UART data buffer 7 register LDB07/LDB17 R/W – √ – 00H
F06DFH LIN/UART data buffer 8 register LDB08/LDB18 R/W – √ – 00H
F06E0H UART operation enable register LUOER0/LUOER1 R/W – √ – 00H
F06E1H UART option register 1 LUOR01/LUOR11 R/W – √ – 00H
F06E4H UART transmit data register LUTDR0L/
LUTDR1L
LUTDR0/
LUTDR1
R/W – √ √ 0000H
F06E5H LUTDR0H/
LUTDR1H
– √
F06E6H UART receive data register LURDR0L/
LURDR1L
LURDR0/
LURDR1
R – √ √ 0000H
F06E7H LURDR0H/
LURDR1H
– √
Note These registers are allocated to the RAM window 1 for the CAN module (receive buffer, receive FIFO buffer,
transmit/receive FIFO buffer, transmit buffer, and transmit history data). When setting these registers, set the
RPAGE bit in the GRWCR register to 1.
