Renesas RL78 Series User Manual

RL78/F13, F14 CHAPTER 3 CPU ARCHITECTURE
R01UH0368EJ0210 Rev.2.10 183
Dec 10, 2015
Table 3-6. Extended SFR (2nd SFR) List (32/32)
Address Special Function Register (2nd SFR) Name Symbol R/W Manipulable Bit Range After
reset
1-bit 8-bit 16-bit
F06E8H UART wait transmit data register LUWTDR0L/
LUWTDR1L
LUWTDR0/
LUWTDR1
R/W – √ √ 0000H
F06E9H LUWTDR0H/
LUWTDR1H
– √
F06F0H Timer RJ counter register 0 TRJ0 R/W – – √ FFFFH
F06F1H
F0780H Event output destination select register 00 ELSELR00 R/W √ √ – 00H
F0781H Event output destination select register 01 ELSELR01 R/W √ √ – 00H
F0782H Event output destination select register 02 ELSELR02 R/W √ √ – 00H
F0783H Event output destination select register 03 ELSELR03 R/W √ √ – 00H
F0784H Event output destination select register 04 ELSELR04 R/W √ √ – 00H
F0785H Event output destination select register 05 ELSELR05 R/W √ √ – 00H
F0786H Event output destination select register 06 ELSELR06 R/W √ √ – 00H
F0787H Event output destination select register 07 ELSELR07 R/W √ √ – 00H
F0788H Event output destination select register 08 ELSELR08 R/W √ √ – 00H
F0789H Event output destination select register 09/
A/D converter trigger select register 0
Note
ELSELR09/ADTRGS0
Note
R/W √ √ – 00H
F078AH Event output destination select register 10 ELSELR10 R/W √ √ – 00H
F078BH Event output destination select register 11 ELSELR11 R/W √ √ – 00H
F078CH Event output destination select register 12 ELSELR12 R/W √ √ – 00H
F078DH Event output destination select register 13/
A/D converter trigger select register 1
Note
ELSELR13/ADTRGS1
Note
R/W √ √ – 00H
F078EH Event output destination select register 14 ELSELR14 R/W √ √ – 00H
F078FH Event output destination select register 15 ELSELR15 R/W √ √ – 00H
F0790H Event output destination select register 16 ELSELR16 R/W √ √ – 00H
F0791H Event output destination select register 17 ELSELR17 R/W √ √ – 00H
F0792H Event output destination select register 18 ELSELR18 R/W √ √ – 00H
F0793H Event output destination select register 19 ELSELR19 R/W √ √ – 00H
F0794H Event output destination select register 20 ELSELR20 R/W √ √ – 00H
F0795H Event output destination select register 21 ELSELR21 R/W √ √ – 00H
F0796H Event output destination select register 22 ELSELR22 R/W √ √ – 00H
F0797H Event output destination select register 23 ELSELR23 R/W √ √ – 00H
F0798H Event output destination select register 24 ELSELR24 R/W √ √ – 00H
F0799H Event output destination select register 25 ELSELR25 R/W √ √ – 00H
Note RL78/F13 only.
Remark For SFRs in the SFR area, see Table 3-5 SFR List.
