RL78/F13, F14 CHAPTER 4 PORT FUNCTIONS

R01UH0368EJ0210 Rev.2.10 252

Dec 10, 2015

Figure 4-37. Block Diagram of P64

P64/(TI14)/(TO14)

(SNZOUT3)

PORT

P64

(TO14)/

(SNZOUT3)

PM6

P-ch

PU6

PM64

PU64

PMS

PMS0

Internal bus

Output latch

Alternate function

Selector

P6: Port register 6

PU6: Pull-up resistor option register 6

PM6: Port mode register 6

PMS: Port mode select register

RD: Read signal

WRxx: Write signal
