RL78/F13, F14 CHAPTER 4 PORT FUNCTIONS

R01UH0368EJ0210 Rev.2.10 269

Dec 10, 2015

Figure 4-48. Block Diagram of P77

P77/KR7/INTP12

(SSI10)

PORT

WRPM

PU77

KR7/INTP12/

/(SSI10)

P77

PM77

EVDD

P-ch

PU7

PM7

WRPMS

PMS

PMS0

PITHL7

PITHL77

WRPITHL

CMOS

(Schmitt3)

CMOS

(Schmitt1)

Internal bus

Output latch

Alternate function

Selector

P7: Port register 7

PU7: Pull-up resistor option register 7

PM7: Port mode register 7

PMS: Port mode select register

PITHL7: Port input threshold control register 7

RD: Read signal

WRxx: Write signal
