Figures 4-61 to 4-65 show block diagrams of port 12 for 100-pin products.
Figure 4-61. Block Diagram of P120
P120/ANI25/TI07
/
TO07/TRDIOD0/
SO01/INTP4
WR
PU
RD
WR
PORT
WR PM
PU120
P120
PM120
EV DD
P-ch
PU12
PM12
P12
WR PMC
PMC12
PMC120
WR PMS
WR POM
PMS
PMS0
POM120
POM12
TO07/TRDIOD0
SO01
TI07/TRDIOD0
/INTP4
Internal bus
Output latch
Alternate function
Alternate function
Alternate function
Selector
A/D converter
ADS
ADS4 to ADS0
P12: Port register 12
PU12: Pull-up resistor option register 12
PM12: Port mode register 12
POM12: Port output mode register 12
PMC12: Port mode control register 12
PMS: Port mode select register
ADS: Analog input channel specification register
RD: Read signal
WRxx: Write signal
