RL78/F13, F14 CHAPTER 4 PORT FUNCTIONS

R01UH0368EJ0210 Rev.2.10 291

Dec 10, 2015

Figure 4-62. Block Diagram of P121 and P122

Clock generator

Internal bus

P122/X2/EXCLK

EXCLK, OSCSEL

CMC

OSCSEL

CMC

P121/X1

CMC: Clock operation mode control register

RD: Read signal
