Renesas RL78 Series User Manual

RL78/F13, F14 CHAPTER 6 TIMER ARRAY UNIT
R01UH0368EJ0210 Rev.2.10 431
Dec 10, 2015
The presence or absence of timer I/O pins in each timer array unit channel depends on the product.
Table 6-2. Timer I/O Pins provided in Each Product
Timer array unit channels I/O Pins of Each Product
Group E Products Group B, C, and D Products Group A Products
Unit 0 Channel 0 P17/TI00/TO00
Channel 1 P30/TI01/TO01
Channel 2 P16/TI02/TO02
Channel 3 P125/TI03/TO03
Channel 4 P13/TI04/TO04
Channel 5 P15/TI05/TO05
Channel 6 P14/TI06/TO06
Channel 7 P120/TI07/TO07
Unit 1 Channel 0 P41/TI10/TO10

Channel 1 P12/TI11/TO11

Channel 2 P11/TI12/TO12

Channel 3 P10/TI13/TO13

Channel 4 P31/TI14/TO14
 
Channel 5 P70/TI15/TO15
 
Channel 6 P32/TI16/TO16
 
Channel 7 P71/TI17/TO17
 
Remarks 1. When timer input and timer output are shared by the same pin, either only timer input or only timer output can
be used.
2. : The channel is not available.
3. For details on Groups A to E, see the first page of CHAPTER 6.
