Renesas RL78 Series User Manual

RL78/F13, F14 CHAPTER 6 TIMER ARRAY UNIT
R01UH0368EJ0210 Rev.2.10 462
Dec 10, 2015
Figure 6-25. Format of Noise Filter Enable Register 1 (NFEN1) (1/2)
Address: F0071H After reset: 00H R/W
Symbol 7 6 5 4 3 2 1 0
NFEN1 TNFEN07 TNFEN06 TNFEN05 TNFEN04 TNFEN03 TNFEN02 TNFEN01 TNFEN00
TNFEN07 Enable/disable using noise filter of TI07 pin input signal
0 Noise filter OFF
1 Noise filter ON
TNFEN06 Enable/disable using noise filter of TI06 pin input signal
0 Noise filter OFF
1 Noise filter ON
TNFEN05 Enable/disable using noise filter of TI05 pin input signal
0 Noise filter OFF
1 Noise filter ON
TNFEN04 Enable/disable using noise filter of TI04 pin input signal
0 Noise filter OFF
1 Noise filter ON
TNFEN03 Enable/disable using noise filter of TI03 pin input signal
0 Noise filter OFF
1 Noise filter ON
TNFEN02 Enable/disable using noise filter of TI02 pin input signal
0 Noise filter OFF
1 Noise filter ON
TNFEN01 Enable/disable using noise filter of TI01 pin input signal
0 Noise filter OFF
1 Noise filter ON
TNFEN00 Enable/disable using noise filter of TI00 pin input signal
0 Noise filter OFF
1 Noise filter ON
Caution The pin to be used can be changed by setting the TIS17 and TIS16 bits in the timer input select
register 1 (TIS1).
When TIS17, TIS16 = 0, 0: The use of the noise filter of the TI07 pin can be enabled or disabled.
When TIS17, TIS16 = 1, 0: The use of the noise filter of the RxD0 pin can be enabled or disabled.
Remark The presence or absence of timer I/O pins of channel 0 to 7 depends on the product. See Table 6-2 Timer
I/O Pins provided in Each Product for details.
