RL78/F13, F14 CHAPTER 12 A/D CONVERTER

R01UH0368EJ0210 Rev.2.10 734

Dec 10, 2015

Figure 12-20. Conversion Operation of A/D Converter (Software Trigger Mode)

A/D conversion operations are performed continuously until bit 7 (ADCS) of the A/D converter mode register (ADM) is

reset (0) by software.

If a write operation is performed to the analog input channel specification register (ADS) during an A/D conversion

operation, the conversion operation is initialized, and if the ADCS bit is set (1), conversion starts again from the beginning.

Reset signal generation clears the A/D conversion result register (ADCR, ADCRH) to 0000H or 00H.

Sampling time

Sampling A/D conversion

Undefined

A/D converter

operation

ADCS ← 1 or ADS rewrite

SAR

ADCR

INTAD

SAR clear

Conversion time

Conversion

result

Conversion

result
