RL78/F13, F14 CHAPTER 15 SERIAL ARRAY UNIT

R01UH0368EJ0210 Rev.2.10 885

Dec 10, 2015

Figure 15-65. Procedure for Stopping Slave Transmission/Reception

Remarks 1. Even after communication is stopped, the pin level is retained. To resume the operation, re-set serial

output register m (SOm) (see Figure 15-66 Procedure for Resuming Slave

Transmission/Reception).

2. m: Unit number (m = 0, 1), n: Channel number (n = 0, 1), p: CSI number (p = 00, 01, 10, 11),

mn = 00, 01, 10, 11

Starting setting to stop

Stopping communication

Write 1 to the STmn bit of the target

channel.

Stop communication in midway.

Changing setting of the SOEm register

Set the SOEmn bit to 0 and stop the

output of the target channel.

Setting the STm register
