3. Press and hold the [A] key and "Check Status [B]" at the same time until the number
keyboard screen is displayed.
4. Enter the key code for SP mode.
5. Perform line adjustment.
1. Execute SP2-111-004 (Forced Line Position Adj. Mode d)
2. The result can be checked with SP2-194-007 (MUSIC Execution Result Execution Result)
0: Success, 1: Failure
Also, results for each color can be checked with SP2-194-010 to 013 (MUSIC Execution
Result: Error Result C, M, Y, K).
1: Completed successfully
6. Exit the SP mode.
Main Machine Installation
93
