Name Output connector
Capacity Part number
Market exchange
possible
Voltage Part name Remarks
FU102 CN988 (DC power supply)
15A(NA)
11071241(NA)
11071366
Yes
AC
TLC-15A-N4
(NA)
FIH 250V
8A(EM)8A
Installed on AC control
board
FU110
CN921(Heater for Tray1, 2,
and optional trays)
CN922 (Heater for Scanner
and PCU)
2A 11071225 NO
AC SLT 250V 2A
Installed on Heater
Board (Service Part)
FU105 None
2A 11071362 NO
AC SCT2A
Installed on AC control
board
FU1 CN911(IOB)
5A 11071229 NO
5V SLT 250V 5A
Installed on DC power
supply
FU2 CN911(IPU)
5A 11071229 NO
5V SLT 250V 5A
Installed on DC power
supply
FU3 CN912(IOB)
8A Yes
24V 51MS(P)080L
Installed on DC power
supply
FU4
CN917 (Interlock switch
[IOB])
8A Yes
24V 51MS(P)080L
Installed on DC power
supply
FU5
CN917 (Interlock switch
[IOB])
8A Yes
24V 51MS(P)080L
Installed on DC power
supply
