Ricoh MP C3004 - Page 1164

To Next Page

To Previous Page

Name Output connector

Capacity Part number

Market exchange

possible

Voltage Part name Remarks

FU7

CN913(FIN)

CN914(BANK)

8A Yes

24V 51MS(P)080L

Installed on DC power

supply

Fuse position

6. Troubleshooting

1156
