5-803-076 1 Bin Tray: Set Detection System ENG [0 or 1 / 0 / 1/step]
0: paper exist
1: paper non exist
Detects that tray is set to main unit.
(0: set, 1:not set)
5-803-077 Bridge Relay Sensor ENG [0 or 1 / 0 / 1/step]
0: paper exist
1: paper non exist
Responds to paper existence on carry sensor position or bridge unit.
(0: paper exist, 1: paper non exist)
5-803-078 Bridge Exit Sensor ENG [0 or 1 / 0 / 1/step]
0: Paper exist
1: Paper do not exist
Responds to paper existence on paper exit sensor position or bridge unit.
(0: paper exist, 1: paper non exist)
5-803-079 Bridge Set Detection System ENG [0 or 1 / 0 / 1/step]
10: set
11:not set
Detects that bridge unit is set to main unit.
(10: set, 11:not set)
5-803-082 Bridge Relay/Left Exit Cover
Sensor
ENG [0 or 1 / 0 / 1/step]
0: close
1: open
Detects open/close of the left carry cover open/close sensor (left paper exit tray) and
the relay carry cover open/close sensor (bridge unit).
(0: close, 1: open)
Input and Output Check
571
