5-803-083 Bridge Exit/Upper Exit Cover
Sensor
ENG [0 or 1 / 0 / 1/step]
0: close
1: open
Detects open/close of the upper carry cover open/close sensor (left paper exit tray)
and the relay paper exit cover open/close sensor (bridge unit).
(0: close, 1: open)
5-803-084 Shift Tray: Set Detection System ENG [0 or 1 / 0 / 1/step]
01: set
11:not set
Detects that shift tray is set to main unit.
(01: set, 11:not set)
5-803-085 Shift Tray: Position Sensor 1 ENG [0 or 1 / 0 / 1/step]
0: Stop on this side. during moving
towards inner
1: Stop on inner side. during moving
towards this side
Detects shift tray position.
(0: Stop on this side. during moving towards inner,
1: Stop on inner side. during moving towards this side)
5-803-086 Shift Tray: Position Sensor 2 ENG [0 or 1 / 0 / 1/step]
*It is a backup sensor with this machine, so "1" is always displayed)
5-803-094 GAVD Open/Close Detection ENG [0 or 1 / 0 / 1/step]
For checking door open/close during process. No need to operate.
5-803-095 Bridge 24V Fuse Detection ENG [0 or 1 / 0 / 1/step]
0: Not cut
1: Cut
Detects state of 24V fuse on the bridge unit.
(0: Not cut, 1: Cut)
3. Engine SP Mode Tables
572
