5804 [OUTPUT Check]
5-804-104 Polygon Motor: L ENG [0 or 1 / 0 / 1/step]
Runs motor with 21969 rpm.
5-804-105 Polygon Motor: M ENG [0 or 1 / 0 / 1/step]
Runs motor with 25512 rpm.
5-804-106 Polygon Motor: H ENG [0 or 1 / 0 / 1/step]
Runs motor with 30236 rpm.
5-804-107 Polygon Motor: HH ENG [0 or 1 / 0 / 1/step]
Runs motor with 34488 rpm.
5-804-110 Fusing Fan: Full Speed ENG [0 or 1 / 0 / 1/step]
Moves fusing exhaust heat fan.
5-804-111 Fusing Fan: Half Speed ENG [0 or 1 / 0 / 1/step]
Moves fusing exhaust heat fan.
5-804-113 PSU Cooling/Exhaust Heat
Fan
ENG [0 or 1 / 0 / 1/step]
Moves PSU cooling fan and exhaust heat fan.
5-804-114 Ozone Fan ENG [0 or 1 / 0 / 1/step]
Moves ozone exhaust heat fan.
5-804-115 PCB Box Cooling Fan: Full
Speed
ENG [0 or 1 / 0 / 1/step]
Moves electric BOX cooling fan.
5-804-116 PCB Box Cooling Fan: Half
Speed
ENG [0 or 1 / 0 / 1/step]
Moves electric BOX cooling fan.
5-804-117 Development: Right/
DriveCooling/MainFan
ENG [0 or 1 / 0 / 1/step]
Moves main unit exhaust heat fan, develop right exhaust air fan, driver cooler.
Input and Output Check
593
