5-804-118 ExhaustCooling Fan ENG [0 or 1 / 0 / 1/step]
Moves paper exit cooling fan.
5-804-119
Development Solenoid ENG [0 or 1 / 0 / 1/step]
Moves development solenoid.
5804 [OUTPUT Check]
Moves develop motor.
5-804-120 Development Motor K:
Standard Speed
ENG [0 or 1 / 0 / 1/step]
5-804-121 Development Motor K:
Middle Speed
ENG
5-804-122 Development Motor K: Low
Speed
ENG
5-804-128 Development Motor FC:
Standard Speed
ENG
5-804-129 Development Motor FC:
Middle Speed
ENG
5-804-130 Development Motor FC:
Low Speed
ENG
5804 [OUTPUT Check]
Moves/Stops drum motor FC.
* Execute this SP after correcting the cam position so that ITB contact/separation
lever of the color station is released.
5-804-132 Drum Motor FC: Standard
Speed
ENG [0 or 1 / 0 / 1/step]
5-804-133 Drum Motor FC: Middle
Speed
ENG
5-804-134 Drum Motor FC: Low Speed ENG
3. Engine SP Mode Tables
594
