5804 [OUTPUT Check]
Moves/Stops transfer drum motor K.
* Execute this SP after correcting the cam position so that ITB contact/separation
lever of the color station is released.
5-804-136 Transfer Drum Motor K:
Standard Speed
ENG [0 or 1 / 0 / 1/step]
5-804-137 Transfer Drum Motor K:
Middle Speed
ENG
5-804-138 Transfer Drum Motor K: Low
Speed
ENG
5804 [OUTPUT Check]
Moves paper transfer divide motor.
5-804-140 PTR Contact Motor:CW ENG [0 or 1 / 0 / 1/step]
5-804-141 PTR Contact Motor:CCW ENG
5804 [OUTPUT Check]
Moves toner supply motor.
Replenish forcibly the color you want to use.
* If driving this motor only, do not drive it more than 2 seconds.
5-804-142 Toner Supply Motor Y:
Standard Speed
ENG [0 or 1 / 0 / 1/step]
5-804-146 Toner Supply Motor
M:CCW:Standard Speed
ENG [0 or 1 / 0 / 1/step]
5804 [OUTPUT Check]
Moves image transfer divide motor (reverse to toner supply motor M).
* Execute this SP after correcting the cam position so that ITB contact/separation
lever of the color station is released.
5-804-150 Toner Supply Motor M:CW:
(ITB Contact)
ENG [0 or 1 / 0 / 1/step]
Input and Output Check
595
