5804 [OUTPUT Check]
Moves toner supply motor.
Replenish forcibly the color you want to use.
* If driving this motor only, do not drive it more than 2 seconds.
5-804-151 Toner Supply Motor C:
Standard Speed
ENG [0 or 1 / 0 / 1/step]
5-804-155 Toner Supply Motor K:
Standard Speed
ENG [0 or 1 / 0 / 1/step]
5804 [OUTPUT Check]
Moves toner bottle drive motor.
* Execute this SP after removing the toner bottle.
If driving this motor while attaching the toner bottle, do not drive it more than 2
seconds.
5-804-159 Toner Bottle Drive Motor Y ENG [0 or 1 / 0 / 1/step]
5-804-160 Toner Bottle Drive Motor M ENG
5-804-161 Toner Bottle Drive Motor C ENG
5-804-162 Toner Bottle Drive Motor K ENG
5804 [OUTPUT Check]
Moves relay carry motor (bridge unit)/left paper exit carry motor (left paper exit
tray).
5-804-163 Bridge Relay/Left Exit
Motor: Normal Speed
ENG [0 or 1 / 0 / 1/step]
5-804-164 Bridge Relay/Left Exit
Motor: Middle Speed
ENG
5-804-165 Bridge Relay/Left Exit
Motor: Low Speed
ENG
5-804-166 Bridge Relay/Left Ex Mt:
Normal Speed Upper
ENG
5804 [OUTPUT Check]
3. Engine SP Mode Tables
596
