5-804-202 Scanner Lamp ENG [0 or 1 / 0 / 1/step]
Checks output of scanner lamp.
Use to check light source malfunction when SC101-01, SC101-02, SC102-00,
SC142-00 occurs.
5-804-206 PTR Open/Close LED ENG [0 or 1 / 0 / 1/step]
Lights paper transfer open/close LED.
5-804-208 TM/P Sensor: F ENG [0 or 1 / 0 / 1/step]
Lights TM/P sensor: Front glowing part.
5-804-209 TM/P Sensor: C ENG [0 or 1 / 0 / 1/step]
Lights TM/P sensor: Center glowing part.
5-804-210 TM/P Sensor: R ENG [0 or 1 / 0 / 1/step]
Lights TM/P sensor: Rear glowing part.
5-804-211 Toner Sensor Power ENG [0 or 1 / 0 / 1/step]
5-804-232 Toner IDTAG Power ENG [0 or 1 / 0 / 1/step]
5804 [OUTPUT Check]
5-804-235 Fusing Shading Plate M:
CW
ENG [0 or 1 / 0 / 1/step]
Moves shade plate of fusing Md to CW direction.
* Execute this SP after removing the fusing unit.
Continuing to turn the fusing shield drive motor while attaching the fusing unit, the
units may be damaged.
Procedure:
1. Remove the fusing unit.
2. Remove the waste tonner bottle.
3. Execute this SP.
Input and Output Check
599
