5-804-236 Fusing Shading Plate M:
CCW
ENG [0 or 1 / 0 / 1/step]
Moves shade plate of fusing Md to CCW direction.
* Execute this SP after removing the fusing unit.
Continuing to turn the fusing shield drive motor while attaching the fusing unit, the
units may be damaged.
Procedure:
1. Remove the fusing unit.
2. Remove the waste tonner bottle.
3. Execute this SP.
5-804-239 Fusing Exit Drive Solenoid ENG [0 or 1 / 0 / 1/step]
5804 [OUTPUT Check]
Continuously drives specified motor for operation test.
5-804-241 Bank: Tray3: Feed Mt:
Standard Speed
ENG [0 or 1 / 0 / 1/step]
5-804-242 Bank: Tray4: Feed Mt:
Standard Speed
ENG
5-804-243 Bank: Tray5: Feed Mt:
Standard Speed
ENG
5-804-244 Bank: Tray3: Transport Mt:
Standard Speed
ENG
5-804-245 Bank: Tray4: Transport Mt:
Standard Speed
ENG
5-804-246 Bank: Tray5: Transport Mt:
Standard Speed
ENG
5804 [OUTPUT Check]
Drives specified motor for a certain period of time to test operation.
5-804-247 Bank: Tray3: PU Solenoid ENG [0 or 1 / 0 / 1/step]
5-804-248 Bank: Tray4: PU Solenoid ENG
5-804-249 Bank: Tray5: PU Solenoid ENG
3. Engine SP Mode Tables
