10. Open the right door, and then remove the small cover [A].
11. Remove the proximity sensor cover [A].
• Remember that there are three tabs at the positions of the red arrows.
• Tilt the operation panel [B] upward to a horizontal position, and then remove the proximity
sensor cover [A].
