14. Connect the harness of the hopper sensor to the connector of the finisher.

15. Connect the harness of the punch unit to the connector of the registration drive unit.

16. Connect the harness of the punch unit to the main board, and then clamp it. ( ×2,

×2)

Punch Unit PU3060 (D706)

257
