8. When installing the punch unit in a finisher that is already installed, remove the relay
guide plate [A] ( ×2).
• This step is unnecessary when installing the finisher and punch unit at the same time.
9. Attach the punch unit cover [A] provided with the accessories, inserting the tabs ( ×1).
Punch Unit PU3040 (D716)
315
