13. Attach the left rear cover.
14. Insert the upper left cover [A] from the front, and slide it to attach it.
15. Attach stabilizers [A].
• Because the weight is biased to the right of the machine if the internal finisher is installed,
stabilizers are required on the left side. Because they are included with the finisher, install
these stabilizers at the same time as you install the internal finisher.
Punch Unit PU3040 (D716)
317
