SC No. Type Error Name/Error Condition/Major Cause/Solution
SC722-44 B Stapler Motor Error
• Motor driver detects an error (short-circuit or overheating) (1st time
is SC).
• During movement to home, the home position could not be detected
even after a predetermined time elapsed (1st time is jam notification,
2nd time is SC notification).
• During movement from home, the home position was detected even
after a predetermined time elapsed (1st time is jam notification, 2nd
time is SC notification).
• During motor drive, the output from the encoder could not be
counted for a predetermined number of times within a
predetermined time (1st time is jam notification, 2nd time is SC
notification).
SC722-45 B Stapleless Stapler Transfer Motor Error
• Motor driver detects an error (short-circuit or overheating) (1st time
is SC).
• During movement to home, the home position could not be detected
within a predetermined pulse (1st time is jam notification, 2nd time is
SC notification).
• During movement from home, the home position was detected even
after a predetermined pulse elapsed (1st time is jam notification,
2nd time is SC notification).
SC722-46 B Stapleless Stapler Motor Error
• Motor driver detects an error (short-circuit or overheating) (1st time
is SC).
• During movement to home, the home position could not be detected
even after a predetermined time elapsed (1st time is jam notification,
2nd time is SC notification).
• During movement from home, the home position was detected even
after a predetermined time elapsed (1st time is jam notification, 2nd
time is SC notification).
Service Call 700-792
989
