SC No. Type Error Name/Error Condition/Major Cause/Solution
SC722-27 B Punch Movement Motor Error
SC722-28 B Punch Horizontal Registration Detection Error
SC722-30 B Jogger Motor 1 Error
SC722-33 B Positioning Roller Motor Error
SC722-41 B Release Motor Error
• During movement to home, the home position could not be detected
within a predetermined pulse (1st time is jam notification, 2nd time is
SC notification).
• During movement from home, the home position was detected even
after a predetermined pulse elapsed (1st time is jam notification,
2nd time is SC notification).
SC722-42 B Stapler Retreat Motor Error
• During movement to home, the home position could not be detected
within a predetermined pulse (1st time is jam notification, 2nd time is
SC notification).
• During movement from home, the home position was detected even
after a predetermined pulse elapsed (1st time is jam notification,
2nd time is SC notification).
• During movement from home, retreat sensor ON could not be
detected even after a predetermined pulse elapsed (1st time is jam
notification, 2nd time is SC notification).
• During initialization, retreat sensor ON was detected simultaneously
when the home position is detected (1st time is jam notification, 2nd
time is SC notification).
6. Troubleshooting
988
