Siemens ARCADIS Varic Operator's Manual

Operator Manual
22
of 78 SPR2-310.620.30.02.02
Image Processing
Scrolling with the
scroll bar
The third way of scrolling through the images and series of a study is to use the
scroll bar.
(1) Scroll arrow for first page
(2) Scroll symbol for previous page
(3) Scroll arrow for previous page
(4) Slider
(5) Scroll arrow for next page
(6) Scroll symbol for next page
(7) Scroll arrow for last page
The position of the slider only refers to the specific series through which you are
currently scrolling and not to all images currently loaded in the Viewing task card.

Siemens ARCADIS Varic Specifications

General

Type	Mobile C-arm
Image Intensifier	9-inch or 12-inch
DICOM Compatibility	Yes
Frame Rate	Up to 30 fps
Focal Spot Size	0.3/0.6 mm
Monitor	Dual 18-inch TFT LCD monitors
