Siemens ARCADIS Varic Operator's Manual

System Description
ARCADIS Varic
SPR2-310.620.30.02.02 39
of 44
Unplugging the
central plug
◆ Turn the lever counterclockwise for unlocking and remove the plug.
– The central plug is disconnected from the monitor trolley.
◆ If attached, disconnect the grounding cable from the C-arm system.
Rolling up the
footswitch cable
(1) Rolling up the footswitch cable
(2) Footswitch holder
◆ Roll up the footswitch cable onto the cleat provided and place the footswitch
into its holder.
When attaching the footswitch, please be careful not to kink the cable.
(2)
(1)

Siemens ARCADIS Varic Specifications

General

Type	Mobile C-arm
Image Intensifier	9-inch or 12-inch
DICOM Compatibility	Yes
Frame Rate	Up to 30 fps
Focal Spot Size	0.3/0.6 mm
Monitor	Dual 18-inch TFT LCD monitors
