Commands listed in alphabetical order

BUS:B2:AUDIO:

DATA:THRESHOLD?

might return

:BUS:B2:AUDIO:DATA:THRESHO LD 500.0000E-3 indicates the Bus 2 audio data

source threshold is set to 500 mV.

BUS:B<x>:AU

Dio:DATa:WORDSize

This command sets or queries the audio bits per word for the speciﬁed bus. The

bus is speciﬁed by x.

Group

Bus

Syntax

BUS:B<x>:AUDio:DATa:WORDSi ze <NR1>

BUS:B<x>:AUDio:DATa:WORDSi ze?

Arguments

<NR1> is the audio bits per word for the s peciﬁed bus.

Examples

BUS:B1:AUDio:DATa:WORDSize 24 sets the audio bits per word to 24 bits.

BUS:B1:AUDio:DATa:WORDSize ? might return

:BUS:B1:AUDIO:DATA:WORDSIZ E 24 indicating the bits per word is 24.

BUS:B<x>:AUDio:FRAME:CLOCKBITSPERCHANNEL

This command sets or queries the audio bits of sync width for the speciﬁed bus.

The bus is speciﬁed by x.

NOTE. This command only applies to the TDM Audio type.

Conditions

Requires option SR-AUDIO.

Group

Bus

Syntax

BUS:B<x>:AUDio:FRAME:CLOCK BITSPERCHANNEL <NR1>

BUS:B<x>:AUDio:FRAME:CLOCK BITSPERCHANNEL?

Arguments

<NR1> is the audio bits of sync width for the speciﬁed bus.

MSO54, MSO56, MSO58, MSO58LP Programmer 2-123
