Tektronix MSO54 Programmer's Manual

Commands listed in alphabetical order
NOTE. WAVEView
<x>
is the specified waveview and must be WAVEView1 .
Cursor<x> is the specified cursor and must be CURSOR1 .
Group
Cursor
Syntax
DISplay:WAVEView<x>:CURSo r:CURSOR<x>:ONEOVERDELTATVALUE?
Returns
The one over delta T cursor readout value of the specified cursor in the specified
waveview.
Examples
DISplay:WAVEView1:CURSor: CURSOR1:ONEOVERDELTATVALUE? might
return
:DISPLAY:WAVEVIEW1:CURSOR:CU RSOR1:ONEOVERDELTATV
ALUE
179.3188E+3
indicating the one over delta time value is 179.3 kHz.
DISplay:WAVEView<x>:CURSor:CURSOR<x>:SCREEN:AXPOSition
Sets or queries the horizontal cursor A position of the specified cursor in the
specified waveview.
NOTE.
WAVEView<x> is the specified waveview and must be WAVEView1 .
Cursor<x> is the specified cursor and must be CURSOR1 .
Group
Cursor
Syntax
DISplay:WAVEView<x>:CURSo r:CURSOR<x>:SCREEN:AXPOSition <NR3>
DISplay:WAVEView<x>:CURSo r:CURSOR<x>:SCREEN:AXPOSition?
Arguments
<NR3> is the horizontal cursor A position of the specified cursor in the specified
waveview.
Examples
DISPLAY:WAVEVIEW1:CURSOR: CURSOR1:SCREEN:AXPOSITION 15.
0E-3
sets the x position of screen cursor1 in waveview1 to 15 mV.
DISPLAY:WAVEVIEW1:CURSOR: CURSOR1:SCREEN:AXPOSITION?
might
return :
DISPLAY:WAVEVIEW1:CURSOR:CU RSOR1:SCREEN:AXPOSITION
-64.0000E-03 indicating that x position of the specified screen cursor in the
specified waveview is set to -64 mV.
2-294 MSO54, MSO56, MSO58, MSO58LP Programmer
