Tektronix MSO54 Programmer's Manual

Commands listed in alphabetical order
Arguments
Arguments are t
he available d ata qualifiers.
NOTE. If the search condition is set to
LABELANDDATA , the label qualifier will be
locked to Equal until the search condition is changed again.
Examples
SEARCH:SEARCH1:TRIGGER:A:B US:ARINC429A:LABEL:QUALIFIER
LESSTHAN
sets the label qualifier to less than.
SEARCH:SEARCH1:TRIGGER:A:B US:ARINC429A:LABEL:QUALIFIER? might
return
EQUAL, indicating that the label qualifier is set to equal.
SEARCH:SEARCH<x>:TRIGger:A:BUS:ARINC429A:LABel:VALue
This command sets or queries the low value when searching on an ARINC429
label field. The search number is specified by x. The search condition must be
set to LABel or LABELANDDATA.
Conditions
Requires the SR-AERO Triggering and Analysis application.
Group
Search and Mark
Syntax
SEARCH:SEARCH<x>:TRIGger:A :BUS:ARINC429A:LABel:VALue
<QString>
Arguments
<QString> is the label value.
Examples
SEARCH:SEARCH1:TRIGGER:A:B US:ARINC429A:LABEL:VALUE
"XXXX1010"
sets the value to XXXX1010.
SEARCH:SEARCH1:TRIGGER:A:B US:ARINC429A:LABEL:VALUE? might return
"XXXXXXXX", indicating that the value is XXXXXXXX.
SEARCH:SEARCH<x>:TRIGger:A:BUS:ARINC429A:SDI:VALue
This command sets or queries the label when searching on an ARINC429 SDI
field. The search number is specified by x. The search condition must be set to
DATa or LABELANDDATA, and the data format must be set to DATA.
Conditions
Requires the SR-AERO Triggering and Analysis application.
MSO54, MSO56, MSO58, MSO58LP Programmer 2-635
