Tektronix MSO54 Programmer's Manual

Commands listed in alphabetical order
Group
Display Contro
l
Syntax
DISplay:WAVEView<x>:BUS:B< x>:VERTical:POSition <NR3 >
DISplay:WAVEView<x>:BUS:B< x>:VERTical:POSition?
Arguments
<NR3> is the vertical position of the specified bus.
Examples
DISplay:WAVEView1:BUS:B1:V
ERTical:POSition 1.0e0
sets the position
to 1 division.
DISplay:WAVEView1:BUS:B1:
VERTical:POSition?
might return
:DISPLAY:WAVEVIEW1:BUS:B1: VERTICAL:POSITION 0.0E+0 indicating
the position is 0.0 divisions.
DISplay:WAVEView<x>:CH<
x>:STATE
Sets or queries the state of the specified channel in the specified waveview.
NOTE.
WAVEView<x > is the specified waveview and must be WAVEView1 .
Group
Display Control
Syntax
DISplay:WAVEView<x>:CH<x>: STATE {<NR1>|OFF|ON}
DISplay:WAVEView<x>:CH<x>: STATE?
Arguments
<NR1> = 0 disables the specified channel on t he specified waveview; any other
value turns this feature on.
OFF disables the display the specified channel on the specified waveview.
ON enables the specified channel on the specified waveview.
Examples
DISplay:WAVEView1:CH1:STAT E ON t
urns on channel 1.
DISplay:WAVEView1:CH1:STAT E? might return
:DISPLAY:WAVEVIEW1:CH1:STA TE 0
indicating channel 1 is off.
MSO54, MSO56, MSO58, MSO58LP Programmer 2-283
