Tektronix MSO54 Programmer's Manual

Commands listed in alphabetical order
Syntax
CH<x>:BANdwid
th {<NR3>| FULl}
CH<x>:BANdwidth?
Arguments
<NR3> is the desired bandwidth. The instrument rounds this value to an available
bandwidth using geometric rounding and then uses this value to set the upper
bandwidth.
FULl disables any optional bandwidth limiting. The specified channel operates at
its maximum bandwidth.
Examples
CH1:BANDWIDTH 20 sets the bandwidth of Channel 1 to 20 MHz.
CH2:BANDWIDTH?, might return :CH2:BA NDWIDTH 500.0000E+06, indicating
that there is bandwidth limiting on Channel 2.
CH<x>:COUPling
This command sets o r queries the input coupling setting for the speci fied analog
channel. The channel is specified by x.
NOTE. The available arguments depend on the attached accessories.
Group
Vertical
Syntax
CH<x>:COUPling {AC|DC|DCREJ}
CH<x>:COUPling?
Arguments
AC sets the specified channel to AC coupling.
DC sets the specified channel to DC coupling.
DCREJect sets DC Reject coupling when probes are attached that support that
feature.
Examples
CH2:COUPLING AC setsChannel2couplingtoAC.
CH3:COUPLING? might return :CH3:COUPLING DC, indicating that Channel 3
is set to DC coupling.
MSO54, MSO56, MSO58, MSO58LP Programmer 2-189

Tektronix MSO54 Specifications

General

Analog Channels	4
Sample Rate	6.25 GS/s
Vertical Resolution	12-bit
Form Factor	Benchtop
Probe Interface	TekVPI
Operating Temperature	0 °C to +50 °C
Bandwidth	1 GHz
Record Length	62.5 Mpoints
Display	15.6 inch HD
Waveform Update Rate	>500, 000 wfms/s
Trigger Types	Edge, Pulse, Runt, Logic, Serial
Serial Bus Support	I2C, SPI, RS-232/422/485/UART, CAN/CAN FD/LIN, USB 2.0, Ethernet
Connectivity	USB, Ethernet
Input Impedance	1 MΩ
Power Requirements	100-240 VAC, 50/60 Hz
Maximum Input Voltage	400 V (DC + peak AC)
