Commands listed in alphabetical order
Examples
DISplay:PLOTV
iew1:CURSor:WAVEform:APOSiti on -50.0E-9
sets the
waveform
APOSITION to -50.0 ns.
DISplay:PLOT
View1:CURSor:WAVEform:APOS ition?
might return
:DISPLAY:PLOTVIEW1:CURSOR: WAVEFORM:APOSITION -60.07 96E-9
indicating the waveform APOSITION issetto-60.08ns.
DISplay:PL
OTView<x>:CURSor:WAVEform:BPOSition
This command sets or q ueries the waveform cursor B horizontal position of the
specified cursor in the specifi ed view.
NOTE. In c
ase of XY plot, this command has no effect when used to set the value.
In case of bathtub plot, this command has no effect. Query returns invalid values.
For all other plots, this command sets or returns the cursor B horizontal position.
Group
Cursor
Syntax
DISplay:PLOTView<x>:CURSor :WAVEform:BPOSition <NR3>
DISplay:PLOTView<x>:CURSor :WAVEform:BPOSition?
Arguments
<NR3> is the horizontal cursor B position.
Examples
DISplay:PLOTView1:CURSor:W AVEform:BPOSition 3.0 sets the position
to 3.0 V.
DISplay:PLOTView5:CURSor:W AVEform:BPOSition? might return
:DISPLAY:PLOTVIEW5:CURSOR: WAVEFORM:BPOSITION 2.6005 17840
indicating the position is 2.5 V.
DISplay:PLOTView<x>:GRIDlines
This command sets or queries the Grid lines setting of the specified plot.
Group
Display Control
Syntax
DISplay:PLOTView<x>:GRIDli nes {HORizontal|VERTical|BOT H}
DISplay:PLOTView<x>:GRIDli nes?
MSO54, MSO56, MSO58, MSO58LP Programmer 2-259
