Commands listed in alphabetical order
DISplay:WAVE
View<x>:MATH:MATH<x>:STATE
This command sets or queries the state of the specified math waveform in the
specified waveview.
NOTE.
WAVEV
iew<x>
is the specified waveview and must be WAVEView1 .
Group
Display Control
Syntax
DISplay:WAVEView<x>:MATH: MATH<x>:STATE {<NR1>|OFF|ON}
DISplay:WAVEView<x>:MATH: MATH<x>:STATE?
Arguments
<NR1> = 0 disables the specified math in the specified waveview; any other value
turnsthisfeatureon.
OFF disables the specifi ed math in the specified waveview.
ON ena bles the specified math in the specified waveview.
Examples
DISplay:WAVEView1:MATH:MA TH1:STATE OFF disables the specified math in
the specified waveview.
DISplay:WAVEView1:MATH:MA TH2:STATE? might return
:DISPLAY:WAVEVIEW1:MATH:M ATH2:STATE 1 indicating the math
is displayed.
DISplay:WAVEView<x>:MATH:MATH<x>:VERTical:POSition
This command sets or queries the vertical position in divisions of the s pecified
math waveform in the specified waveview.
NOTE.
WAVEView<x> is the specified waveview and must be WAVEView1 .
Group
Display Control
Syntax
DISplay:WAVEView<x>:MATH: MATH<x>:VERTical:POSition <NR3>
DISplay:WAVEView<x>:MATH: MATH<x>:VERTical:POSition?
Arguments
<NR3> is the vertical position in d ivisions of the specified math waveform.
2-304 MSO54, MSO56, MSO58, MSO58LP Programmer
