Tektronix MSO54 Programmer's Manual

Command groups
AFG Command Gr
oup
Use the AFG commands for Arbitrary Function Generator functionality. Requires
option AFG.
Table 2-18:
AFG commands
Command Description
AFG:AMPLitude Sets (or queries) the AFG amplitude in volts, peak to peak.
AFG:ARBitrary:SOUrce Sets or queries the source name for the Arbitrary Waveform.
AFG:FREQuency Sets (or queries) the AFG frequency, in Hz.
AFG:FUNCtion Sets (or queries) which AFG function to execute.
AFG:HIGHLevel Sets (or queries) the high level value of the output waveform, in volts.
AFG:LOWLevel Sets (or queries) the low level value of the output waveform, in volts.
AFG:NOISEAdd:PERCent Sets (or queries) the AFG additive noise level as a percentage.
AFG:NOISEAdd:STAT E Sets (or queries) the AFG additive noise state.
AFG:OFFSet Sets (or queries) the AFG offset value, in volts.
AFG:OUTPut:LOAd:IMPEDance Sets (or queries) the AFG output load impedance.
AFG:OUTPut:STATE Sets (or queries) the AFG output state.
AFG:PERIod Sets (or queries) the period of the AFG w aveform, in seconds.
AFG:PULse:WIDth Sets (or queries) the AFG pulse width, in seconds.
AFG:RAMP:SYMmetry Sets (or queries) the AFG ramp symmetry as a percentage.
AFG:SQUare:DUty Sets (or queries) the AFG duty cycle, as a percentage.
2-12 MSO54, MSO56, MSO58, MSO58LP Programmer
