Commands listed in alphabetical order
Syntax
DISplay:WAVEV
iew<x>:PLOT:PLOT<x>:VERTical :POSition <NR3>
DISplay:WAVEView<x>:PLOT:P LOT<x>:VERTical:POSition?
Arguments
<NR3> is the vertical position.
Examples
DISplay:WAVEView1:PLOT:PLO T1:VERTical:POSition 2.0e 0 sets the
position to 2.0 units.
DISplay:WAVEView1:PLOT:PLO T1:VERTical:POSition? might return
:DISPLAY:WAVEVIEW1:PLOT:PL OT1:VERTICAL:POSITION 1.9 918
indicating the position is 1.99 units.
DISplay:WAVEView<x>:PLOT:PLOT<x>:VERTical:SCAle
This command sets or queries the vertical scale of the specified time trend in units
per division in the specified waveview.
Group
Display Control
Syntax
DISplay:WAVEView<x>:PLOT:P LOT<x>:VERTical:SCAle <NR 3>
DISplay:WAVEView<x>:PLOT:P LOT<x>:VERTical:SCAle?
Arguments
<NR3> is the v ertical scale.
Examples
DISplay:WAVEView1:PLOT:PLO T1:VERTical:SCAle 725.0e- 3 sets the
scale to 725 mU
nits.
DISplay:WAVEView1:PLOT:PLO T1:VERTical:SCAle? might return
:DISPLAY:WAV
EVIEW1:PLOT:PLOT1:VERTICAL :SCALE 730.0000E-3
indicating the scale is 730.0 mUnits.
DISplay:WAVEView<x>:REF:REF<x>:STATE
This command sets or queries the state of the specified reference waveform in
the specified waveview.
NOTE.
WAVEView<x > is the specified waveview and must be WAVEView1 .
Group
Display Control
MSO54, MSO56, MSO58, MSO58LP Programmer 2-307
